| Truck Brand | JMC |
| Overall dimensions(mm) | 6235×2030×2550 |
| Total mass (kg) | 7300 |
| Curb weight (kg) | 5140 |
| Fresh Water Tank Capacity(L) | 1500 |
| Hopper Capacity(L) | 4000 |
| Sweeping width(m) | 2.8~3.5(Adjustable) |
| Cleaning speed(km/h) | 5~20(Operating) |
| Number of disks scanned | 4 |
| Suction cup position | mid-mounted |
| Maximum Cleaning Capacity(㎡/h) | ≥60,000 |
| Cleaning water pressure (Mpa) | 16 |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 85 |
| Engine displacement(ml) | 2892 |
| Wheelbase(mm) | 3360 |
| Front and rear axle load | 2600/4700 |
| brake | Air brake |
| Tire size | 7.00R16LT 14PR |
