| Truck Brand | DONGfeng |
| Overall dimensions(mm) | 5325X1655X2270 |
| Total mass (kg) | 3495 |
| Curb weight (kg) | 2650 |
| Fresh Water Tank Capacity(L) | 600 |
| Hopper Capacity(L) | 1500 |
| Sweeping width(m) | 2.8~3.5(Adjustable) |
| Cleaning speed(km/h) | 5~20(Operating) |
| Number of disks scanned | 4 |
| Suction cup position | mid-mounted |
| Maximum Cleaning Capacity(㎡/h) | ≥60,000 |
| Cleaning water pressure (Mpa) | 16 |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 90 |
| Engine displacement(ml) | 1597 |
| Wheelbase(mm) | 2600 |
| Front and rear axle load | 1300/2195 |
| brake | Air brake |
| Tire size | 185R15LT 8PR |
