| Truck Brand | Foton |
| Overall dimensions(mm) | 5200×1750×2300 |
| Total mass (kg) | 4495 |
| Curb weight (kg) | 3900 |
| Fresh Water Tank Capacity(L) | 500L |
| Hopper Capacity(L) | 1500L |
| Sweeping width(m) | 2.8~3.5(Adjustable) |
| Cleaning speed(km/h) | 5~20(Operating) |
| Number of disks scanned | 4 |
| Suction cup position | mid-mounted |
| Maximum Cleaning Capacity(㎡/h) | ≥60,000 |
| Cleaning water pressure (Mpa) | 16 |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 70 |
| Engine displacement(ml) | 2300 |
| Wheelbase(mm) | 2600 |
| Front and rear axle load | 1710/2785 |
| brake | Air brake |
| Tire size | 6.00R15 10PR |
