| Truck Brand | Dongfeng |
| Overall dimensions(mm) | 7930×2500×3200 |
| Total mass (kg) | 18000 |
| Curb weight (kg) | 9480 |
| Fresh Water Tank Capacity(L) | 4000 |
| Hopper Capacity(L) | 8000 |
| Sweeping width(m) | 3.0~3.2(Adjustable) |
| Cleaning speed(km/h) | 3~20(Operating) |
| Maximum Cleaning Capacity(㎡/h) | ≥64,000 |
| Cleaning system components | Sweeping disk bracket, sweeping disk, oil cylinder, oil pipe, connecting rod, adjusting rod, hydraulic motor, etc. |
| Sweeping Brush Deployment Diameter | Φ800-900 |
| Number of Sweeping Disks | 4 |
| 22 |
| The steel part around the suction nozzle in working state is ground clearance | 5~8mm |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 140 |
| Engine displacement(ml) | 4500 |
| Wheelbase(mm) | 4700 |
| Front and rear axle load | 6500/11500 |
| brake | Air brake |
| Tire size | 10.00R20 18PR |
