| Chassis brand | HOWO |
| Body dimensions(mm) | 6900*2350*2840 |
| Tank size(mm) | 3800*1990*1390 |
| Total mass(kg) | 11995 |
| Vehicle quality(kg) | 5395 |
| Rated load mass(kg) | 6405 |
| Engine Model | WP3NQ160E61, 118kw |
| Engine displacement(ml) | 2970 |
| Gearbox | 6th speed |
| Number of spring leaves: | 11/9+7,11/11+7 |
| Tire specifications: | 245/70R19.5 16PR |
| Tank Volume(m³) | 7.7 |
| Tank Thickness（mm） | 5 |
| Tank Body Material | Q235 Carbon Steel |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 30 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
