| Chassis brand | Sinotruk |
| Body dimensions(mm) | 11960*2500*3550 |
| Tank size(mm) | 8630*2490*1842 |
| Total mass(kg) | 32000 |
| Vehicle quality(kg) | 11450 |
| Rated load mass(kg) | 20420 |
| Engine Model | Sinotruk , 257kw |
| Engine displacement(ml) | 7360 |
| Gearbox | Sinotruk 8 speed |
| Number of spring leaves: | Air suspension 2/2/-/- |
| Tire specifications: | 12R22.5 18PR |
| Tank Volume(m³) | 30.6 |
| Tank Thickness（mm） | 5 |
| Tank Body Material | 304 Stainless Steel/Q235 Carbon Steel |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 60 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
