| Chassis brand | Sinotruk |
| Body dimensions(mm) | 11850*2500*3450 |
| Tank size(mm) | 9200*2350*1500 |
| Total mass(kg) | 32000 |
| Vehicle quality(kg) | 11270 |
| Rated load mass(kg) | 20600 |
| Engine Model | Sinotruk MC07.34-60,251kw |
| Engine displacement(ml) | 6870 |
| Gearbox | Sinotruk 8 speed |
| Wheelbase(mm) | 1800+4575+1400 |
| Number of spring leaves: | Air suspension |
| Front wheel braking | Disc brakes |
| Tire specifications: | 315/80R22.5 18PR |
| Tank Volume(m³) | 26000L |
| Tank Thickness（mm） | 5 |
| Tank Body Material | 512 Aluminum Alloy |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 60 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
| Maximum speed(km/h) | 80 |
