| Chassis brand | Chenglong |
| Body dimensions(mm) | 8700*2550*3200 |
| Tank size(mm) | 8950*2490*1650 |
| Total mass(kg) | 18000 |
| Vehicle quality(kg) | 7390 |
| Rated load mass(kg) | 10480 |
| Engine Model | YCS06245-60A,180kw |
| Engine displacement(ml) | 6230 |
| Gearbox | 8JS95E-C, 8 speed |
| Wheelbase(mm) | 4700 |
| Number of spring leaves | Air suspension 2/- |
| Front wheel braking | Disc brakes |
| Tire specifications: | 275/80R22.5 18PR |
| Tank Volume(L) | 16800L |
| Tank Thickness（mm） | 5 |
| Tank Body Material | Q235 Carbon Steel |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 60 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
| Maximum speed(km/h) | 80 |
