| Chassis brand | FAW |
| Body dimensions(mm) | 6230*2030*2750 |
| Tank size(mm) | 3800*1700*1200 |
| Total mass(kg) | 9100 |
| Vehicle quality(kg) | 4000 |
| Rated load mass(kg) | 4905 |
| Engine Model | CA, 100kw |
| Engine displacement(ml) | 2207 |
| Gearbox | 6 speed |
| Wheelbase(mm) | 3600 |
| Number of spring leaves: | 2/3 |
| Front wheel braking | Disc brakes |
| Tire specifications: | 7.5R16 |
| Tank Volume(m³) | 6200L |
| Tank Thickness（mm） | 5 |
| Tank Body Material | Q235 Carbon Steel |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 30 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
| Maximum speed(km/h) | 80 |
