| Chassis brand | SHACMAN |
| Body dimensions(mm) | 8500*2530*3300 |
| Tank size(mm) | 6060*2200*1450 |
| Total mass(kg) | 18000 |
| Vehicle quality(kg) | 6670 |
| Rated load mass(kg) | 11200 |
| Engine Model | B6.2NS6B245, 180kw |
| Engine displacement(ml) | 6200 |
| Gearbox | 8JS95TE-C, 8 speed |
| Wheelbase(mm) | 5100 |
| Number of spring leaves: | Air suspension 3/- |
| Front wheel braking | Disc brakes |
| Tire specifications: | 295/80R22.5 18PR |
| Tank Volume(L) | 15000L |
| Tank Thickness（mm） | 6 |
| Tank Body Material | Q235 Carbon Steel |
| anti wave plate | Yes |
| Oil gas recovery unit | Yes |
| Emergency shutoff valve | Yes |
| Anti-overflow alarm device | Yes |
| Operating Ambient Temperature（°C） | -20~~45 |
| Gear oil pump flow(m³/h) | 60 |
| Fuel loading method | Bottom filling |
| Toolbox | Customized to your needs |
| Mouth of tank | European standard |
| Maximum speed(km/h) | 79 |
