| Overall dimensions（mm） | 9000X2550X3680 |
| Box size（mm） | 5600X2450x550 |
| Total mass（kg） | 18000 |
| Curb Weight（kg） | 11200 |
| Rated load mass（kg） | 6820 |
| Engine power | Weichai,162KW |
| Engine displacement（ml） | 4580 |
| Gearbox | Fast,8 speed |
Maximum lifting mass | 10T |
Working Radius | 14.6m |
Maximum lifting height | 16.5m |
Maximum span of outriggers | 5850mm |
Crane arm | 4 sections |
| Outrigger span | 5100mm |
Rotation angle | 360° full rotation |
Tilt amplitude range | 0°-75° |
Operating Mode | Manual + remote control |
| Tire size | 10.00R20 18PR |
