| Overall dimensions（mm） | 12000X2550X3990 |
| Box size（mm） | 8500X2450x600 |
| Total mass（kg） | 31000 |
| Curb Weight（kg） | 22000 |
| Rated load mass（kg） | 8870 |
| Engine power | Weichai,257KW |
| Engine displacement（ml） | 7800 |
| Gearbox | Sinotruk,12 speed |
Maximum lifting mass | 14T |
Working Radius | 20m |
Maximum lifting height | 22m |
Maximum span of outriggers | 7600mm |
Crane arm | 5 sections |
| Wheelbase | 2200+4300+1350mm |
Rotation angle | 360° full rotation |
Tilt amplitude range | 0°-75° |
Operating Mode | Manual + remote control |
| Tire size | 315/80R22.5 18PR |
