| Brand name | Chenglong |
| Overall Dimensions（mm） | 10195X2550X3450 |
| Wheelbase（mm） | 4500+1350 |
| Box volume（m³） | 22 |
| One feeding cycle time（s） | 12~25 |
| Unloading time（s） | ≤60 |
| Operation mode | Electric control/manual/remote control |
| Tail structure | Flip plate/triangle bucket/floor bucket/swing arm |
| Bucket Type | 120L/240L(660L rack can be added) |
| Engine power（kw） | YCS06270-60,199kw |
| Engine displacement（ml） | 6234 |
| Gearbox | Automatic 8 speed |
| Total mass（kg） | 25000 |
| Curb Weight（kg） | 13940 |
| Front axle/rear axle | 5.5/10X2 |
| Maximum speed（km/h） | 89 |
| Tire specifications | 11.00R20 18PR |
