| Brand name | ISUZU |
| Overall Dimensions（mm） | 7605X2350X3100 |
| Wheelbase（mm） | 3815 |
| Box volume（m³） | 10.5 |
| One feeding cycle time（s） | 12~25 |
| Unloading time（s） | ≤60 |
| Operation mode | Electric control/manual/remote control |
| Tail structure | Flip plate/triangle bucket/floor bucket/swing arm |
| Bucket Type | 120L/240L(660L rack can be added) |
| Engine power（kw） | ISUZU,110kw |
| Engine displacement（ml） | 2499 |
| Gearbox | Automatic 5 speed |
| Total mass（kg） | 9975 |
| Curb Weight（kg） | 6590 |
| Front axle/rear axle | 3/5 |
| Maximum speed（km/h） | 105 |
| Tire specifications | 225/75R17.5 14PR |
