| Brand name | Dong Feng |
| Overall Dimensions（mm） | 7050,7250,7210×2510×3130,3230,3360(mm) |
| Matching garbage collection box volume (m³) | 13 |
| Single cycle time（s） | Up and down once, working cycle time ≤ 40S |
| Unloading time（s） | ≤30 |
| Standard Configuration | Double-bar cylinder, multi-way valve hydraulic control |
| Engine power | 169kw |
| Rated load capacity (kg) | 9675 |
| Gearbox | Automatic 8 speed |
| Total mass（kg） | 18000 |
| Curb Weight（kg） | 8130 |
| Maximum speed（km/h） | 88 |
| Tire specifications | 10.00R20 18PR |
