| Brand name | FOTON |
| Overall Dimensions（mm） | 8365X2550X3250 |
| Wheelbase（mm） | 4500 |
| Box volume（m³） | 14 |
| One feeding cycle time（s） | ≤16 |
| Unloading time（s） | ≤60 |
| Operation mode | Electric control/manual/remote control |
| Tail structure | Flip plate/triangle bucket/floor bucket/swing arm |
| Bucket Type | 120L/240L(660L rack can be added) |
| Engine power（kw） | 180kw |
| Engine displacement（m | 6234 |
| Gearbox | Automatic 8 speed |
| Total mass（kg） | 18000 |
| Curb Weight（kg） | 9190 |
| Maximum speed（km/h） | 90 |
| Tire specifications | 10.00R20 18PR |
