| Brand name | FOTON |
| Overall Dimensions（mm） | 5080X1900X2280 |
| Wheelbase（mm） | 2850 |
| Box volume（m³） | 3.5~5 |
| One feeding cycle time（s） | ≤16 |
| Unloading time（s） | ≤60 |
| Operation mode | Electric control/manual/remote control |
| Tail structure | Flip plate/triangle bucket/floor bucket/swing arm |
| Bucket Type | 120L/240L(660L rack can be added) |
| Engine power（kw） | 85kw |
| Engine displacement（ml） | 2300 |
| Gearbox | Automatic 5 speed |
| Total mass（kg） | 4495 |
| Curb Weight（kg） | 3150 |
| Front axle/rear axle | 4/10 |
| Maximum speed（km/h） | 105 |
| Tire specifications | 6.50R16LT 10PR |
