| Chassis brand | ISUZU |
| Overall dimensions(mm) | 8760*2500*3150 |
| Water tank size(mm) | 4700*2300*1500 |
| Tank volume(L) | 13000 |
| Total mass(kg) | 18000 |
| Empty vehicle mass(kg) | 7780 |
| Rated load mass(kg) | 10090 |
| Wheelbase(mm) | 3360 |
| Engine Model | ISUZU 4HK1-TC60, 151kw |
| Engine displacement(ml) | 5193 |
| Gearbox | ISUZU MLD 6-speed |
| Front and rear axles(T) | 6.3/13 |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | ＞15 |
| Vertical suction lift(m) | ＞7 |
| water pump flow(m³/h)/(l/min) | 60/1000 |
| water pump range(m) | 35 |
Tire size | 295/80R22.5 18PR |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
