| Chassis brand | ISUZU |
| Overall dimensions(mm) | 5990*1980*2530 |
| Water tank size(mm) | 3400*1630*1080 |
| Tank volume(L) | 5000 |
| Total mass(kg) | 7300 |
| Empty vehicle mass(kg) | 3360 |
| Rated load mass(kg) | 3810 |
| Wheelbase(mm) | 3360 |
| Engine Model | 4KH1CN6LB, 88kw |
| Engine displacement(ml) | 2999 |
| Gearbox | ISUZU MSB 5-speed |
| Front and rear axles(T) | 2/5 |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | 15 |
| Vertical suction lift(m) | 7 |
| water pump flow(m³/h) | 20 |
| water pump range(m) | 30 |
Tire size | 7.00R16 |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
