| Chassis brand | Chenglong H5 |
| Overall dimensions(mm) | 10950*2550*3350 |
| Water tank size(mm) | 7300*2450*1650 |
| Tank volume(L) | 19100L |
| Total mass(kg) | 31000 |
| Empty vehicle mass(kg) | 13250 |
| Rated load mass(kg) | 17620 |
| Wheelbase(mm) | 2050+3750+1350 |
| Engine Model | YCK08350-60, 257kw |
| Engine displacement(ml) | 7700 |
| Gearbox | 10JSD160T,10-speed |
| Rear axles(T) | 13 |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | 15 |
| Vertical suction lift(m) | 7 |
| water pump flow(m³/h) | 20 |
| water pump range(m) | 30~35 |
Tire size | 11.00R20 18PR |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
