| Chassis brand | Foton |
| Overall dimensions(mm) | 5995*2200*3300 |
| Water tank size(mm) | 3000*1980*1450 |
| Tank volume(L) | 7000 |
| Total mass(kg) | 4495 |
| Empty vehicle mass(kg) | 750 |
| Rated load mass(kg) | 3550 |
| Wheelbase(mm) | 3360 |
| Engine Model | WP2.3NQ130E61, 96kw |
| Engine displacement(ml) | 2289 |
| Gearbox | 5-speed |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | ＞15 |
| Vertical suction lift(m) | ＞7 |
| water pump flow(m³/h)/(l/min) | 60/1000 |
| water pump range(m) | 35 |
Tire size | 7.00R16LT 8PR |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
