| Chassis brand | FAW |
| Overall dimensions: L*W*H(mm) | 8050*2500*3300 |
| Water tank size(mm) | 4600*2350*1450 |
| Tank volume(L) | 11000L |
| Total mass(kg) | 18000 |
| Empty vehicle mass(kg) | 6910 |
| Rated load mass(kg) | 10960 |
| Wheelbase(mm) | 5300 |
| Engine Model | CA6DH1-22E6, 165kw |
| Engine displacement(ml) | 4800 |
| Gearbox | CA6T138,6-speed |
| Rear axles(T) | 13 |
| Brake | Air brake |
| Emission standards | Euro 6 (Euro 2~5 can be selected) |
| Water cannon range(m) | 30 |
| Sprinkler width(m) | 15 |
| Vertical suction lift(m) | 7 |
| water pump flow(m³/h) | 20 |
| water pump range(m) | 30~35 |
Tire size | 10.00R20 |
| Standard Configuration: | The tank body is made of 4mm high-quality steel, with a sprinkler pump, sprinkler cannon, working platform, power take-off, front flushing, rear sprinkler, universal nozzle, gravity valve, filter, distribution valve, sprinkler head, with self-priming and self-draining function. |
| Optional equipment: | Spray potion tray, potion pump, anti-corrosion and anti-rust inside the water tank, multi-directional water inlet and outlet joints, solenoid valves, pneumatic valves, etc. to meet the needs of different users. |
