| Chassis brand | Foton |
| Overall dimensions(mm) | 5300*2020*2150 |
| Water tank size(mm) | 1460*1500*1000 |
| Tank volume(L) | 1510 |
| Total mass(kg) | 11900 |
| Empty vehicle mass(kg) | 4105 |
| Rated load mass(kg) | 2530 |
| Wheelbase(mm) | 1445 |
| Engine Model | 4F25TC4, 116kw |
| Engine displacement(ml) | 2499 |
| Gearbox | 6-speed |
| Front and rear axles(T) | 1.5/2 |
| Brake | Oil brake |
| Emission standards | Euro 6 |
| Water cannon (gun head) spray lift: | 25-35m |
| Water spraying time: | 25 minutes (depending on flow rate) |
| Vertical suction lift(m) | ＞7 |
| Flow rate: | 13.8L/s |
| Effective water delivery distance of water pump supply: | 15-20m |
Tire size | 265/65R17LT |
| Standard Configuration: | Water spray gun, water suction pipe, water suction filter, water spray belt, horizontal and vertical wave-breaking plates designed inside the water tank, water tank cathode electrophoresis anti-corrosion, water tank water level electronic display meter, water injection and spraying electric switch, electric butterfly valve, centrifugal water pump. |
| Optional equipment: | ETC vehicle-mounted device, rims of different styles, front grille, fog lamp trim, front combination lamp, side pedals, etc. |
