| Truck Brand | FAW |
| Overall dimensions(mm) | 8200×2500×3100 |
| Total mass (kg) | 18000 |
| Curb weight (kg) | 11300 |
| Fresh Water Tank Capacity(L) | 9000 |
| Hopper Capacity(L) | 7000 |
| Sweeping width(m) | 2.8~3.5(Adjustable) |
| Cleaning speed(km/h) | 5~20(Operating) |
| Number of disks scanned | 2 |
| Suction cup position | mid-mounted |
| Maximum Cleaning Capacity(㎡/h) | ≥60,000 |
| Cleaning water pressure (Mpa) | 16 |
| Water pump flow (L/min) | 122 |
| Engine power(kw) | 165 |
| Engine displacement(ml) | 5700 |
| Wheelbase(mm) | 4500 |
| Front and rear axle load | 6500/11500 |
| brake | Air brake |
| Tire size | 10.00R20 |
