| Brand name | JMC |
| Overall Dimensions（mm） | 5515×1980×2190 |
| Matching garbage collection box volume (m³) | 3-5 |
| Single cycle time（s） | Up and down once, working cycle time ≤ 40S |
| Unloading time（s） | ≤30 |
| Standard Configuration | Double-bar cylinder, multi-way valve hydraulic control |
| Engine power | 88kw |
| Rated load capacity (kg) | 4005 |
| Gearbox | Automatic 5 speed |
| Total mass（kg） | 7300 |
| Curb Weight（kg） | 3165 |
| Maximum speed（km/h） | 80 |
| Tire specifications | 7.00R16LT 14PR |
