Technical specifications
| Dimensions（mm） | 9665X2500X3980 |
| Total mass（kg） | 18000 |
| Curb Weight（kg） | 17805 |
| Number of Axles | 2 |
| Number of Tires | 6 |
| Tire Size | 295/80R22.5 16PR |
| Wheelbase (mm) | 4500 |
| Gearbox Model | 6-Speed Manual |
Maximum Operating Height(m) | 30-60m |
Maximum Operating Radius Amplitude(m) | 20m |
Leg Span (transverse/longitudinal) | 6500/6600(mm) |
Outrigger | Front V rear H type |
Slewing Gear | 360 ° Rotation |
Working Mode | Manual+remote control |
Rated load of hanging basket (kg) | 300 |
Fuel Type | Diesel Oil |
Engine Power(kw) | 151 |
| Displacement (ml) | 5193 |
